Product

Infusion Mesh - Extruded
Infusion Mesh – Extruded

Price range: $9.00 through $200.00

SKU N/A Category

Infusion mesh allows the resin to move from the inlet side to the outlet side of the infusion smoothly.  Extruded mesh is suited to flatter and less complex shapes.

–

Key Info:

  • Extruded mesh is rigid and holds its shape in the infusion process
  • Resin flow is fast and even
  • Not as conformable as knitted mesh
  • Easy to remove
  • Less risk of imprinting on laminate
  • Tech info:
    • Weight: 200gsm
    • Width: 1.2m
    • Thickness: 1.3mm
    • Colour: Green
    • Thickness: 1.15mm (approx)
    • Max Temp:120C
    • Material: Polypropylene

–

Available in:

  • Full roll – 50m long
  • By the lineal metre – you add the amount to the cart and we will cut this length for you

–

Additional info:

  • Infusion mesh is added to your layup after the Peel Ply (if you are using this – which we recommend)
    • Overlap mesh slightly at the joins
  • Extruded vs Knitted
    • Extruded better for:
      • Flat panels, hulls
        • Gives fast, even flow and is easy to remove
      • Large simple parts
        • Cheaper than knitted and quick and easy to use
    • Knitted better for:
      • Complex shapes and corners
        • Conforms well and so no bridging
      • Small intricate parts
        • Best fit and less risk of dry spots
